THE SCIENCE OF JUPITER
The largest planet in our solar system, Jupiter is a giant
ball of gas 300 times more massive than earth. It’s five times farther from
the Sun than we are. A year on Jupiter is twelve times longer than ours, but a
Jovian day is only ten hours long. Darting around it are dozens of moons – some
with geysers, volcanoes, or ice. And like the other gas giants – Saturn,
Neptune, and Uranus – Jupiter has rings.
Explore
Interact with the hotspots below to learn more.
-
THE MAGNETOSPHERE
Jupiter’s magnetic field exerts its influence over a vast bubble of charged particles called the magnetosphere.
Jupiter's Magnetosphere
Extending beyond Jupiter’s moons, the Jovian magnetic field is the strongest in the solar system, except for the Sun’s. The field dominates an expansive region called the magnetosphere - the largest structure in the solar system. The magnetic field accelerates electrically charged particles that stream through the magnetosphere. Most of these particles, which are ionized and swept up by the field, come from the volcanic gases spewing from Jupiter’s moon Io.
View Magnetosophere Section -
ORIGIN
Jupiter’s origin is deeply connected to our own, so exploring the giant planet helps us understand where we came from.
Origin
The solar system formed 4.5 billion years ago, when a giant cloud of gas and dust collapsed. Most of this material became the sun and most of what was left over became Jupiter. But many details of this story remain a mystery – how or why this cloud collapsed in the first place, for instance. Jupiter, however, can reveal some of these details.
View Origin Section -
Jupiter and our Solar System
With the exception of the Sun, Jupiter is the most dominant object in the solar system. Because of its size and the fact that it was the first of the gas-giant planets to form, it has profoundly influenced the formation and evolution of all the other planets. For example, Jupiter is the reason why there’s an asteroid belt – and not another planet - between it and Mars. Jupiter has also catapulted countless comets out to the edge of the solar system. Like a gatekeeper, Jupiter has safeguarded Earth from many comet impacts.
The planets are the leftovers from the star-forming process, and Jupiter accounts for the bulk of that material - more than twice that of all the other planets combined. Its atmosphere - predominantly hydrogen and helium - is similar to the composition of the sun and other stars as well as the clouds of gas and dust in our galaxy.
When the sun was born – when it accumulated enough mass for nuclear fusion to ignite – it generated a wind that blew away most of the gas and dust that still remained. The fact that Jupiter’s composition is similar to that of the original cloud suggests that it formed early on, before the wind could clear away that material.
To give you an idea of how dominant Jupiter is, an alien observing our solar system through a telescope would see an average yellow star and Jupiter with three other large planets. Earth and the inner planets would appear merely as debris.
View Solar System Section -
THE INTERIOR
Does Jupiter have a solid core? How does it create the largest magnetic field in the solar system, apart from the Sun?
The Interior
The structure of Jupiter’s interior is a mystery. Juno will investigate the giant planet’s interior structure and search for a core by mapping its magnetic and gravity fields very precisely.
View Interior Section -
Jupiter's Rings
Saturn is famous for its brilliant, icy rings. But all of the gas giants in the solar system have rings – including Jupiter. Unlike Saturn’s rings, Jupiter’s are thin and wispy. And while Galileo first saw Saturn’s rings in 1610, Jupiter’s rings were not discovered until the 1970s, when the Voyager spacecraft visited the planet.
Jupiter’s rings likely formed when chunks of rock or ice crashed into the small moons that now reside within the rings. The collisions blasted dust into space that then encircled the planet.
The ring system is composed of three main parts. On the outside, there’s a pair of faint, gossamer rings. The outermost ring is enclosed inside the orbit of Thebe, one of Jupiter’s moons. The orbit of another moon, Amalthea, forms the outer boundary of the second gossamer ring.
The moons Adrastea and Metis skirt the edges of the flat main ring, which is 6,500 kilometers (4,000 miles) wide.
The third component is made of the same particles as the main ring, but the electromagnetic forces from Jupiter’s magnetosphere shape it into a thick, doughnut shape. Called the halo, it’s about 20,000 to 40,000 kilometers (12,400 to 25,000 miles) thick, although most of the material lies within a few hundred kilometers of the ring plane. -
RADIATION READY?
How do the Juno scientists test and prepare instruments for Jupiter’s extreme radiation environment?
Radiation Ready?
-
SHOEMAKER LEVY 9 IMPACT
In 1994, a comet smashed into Jupiter, creating a cosmic spectacle that caught the world’s attention.
Collisions with Jupiter
Jupiter is the guardian of the inner solar system. Its powerful gravitational field draws comets and other space rocks away from Earth and its neighbors. We now understand how these small objects speed around the solar system far better than ever before, and it turns out that planetary collisions may be more frequent than previously thought. In 1994, comet Shoemaker-Levy 9 gave a spectacular show when it hurtled toward Jupiter, smashing into its thick clouds.
View Collisions Section -
THE ATMOSPHERE
Are the swirls and bands on Jupiter mere surface features, or do they extend deep into the planet?
The Atmosphere of Jupiter
Jupiter’s stunning appearance is due to its atmosphere of swirling clouds and colorful bands, which alternately flow east and west. The atmosphere is mostly hydrogen and helium, but the visible clouds are ammonia. Underneath, there are water clouds. Even after over 200 years, the winds have largely remained unchanged, although the intensity of the colors and width of the bands have varied. The famous Great Red Spot, as big as two Earths, is at least 300 years old. The reds, oranges and other colors arise from chemical reactions, which are probably driven by processes like lightning.
View Atmosphere Section -
MOONS OF JUPITER
Jupiter has more than 60 moons – some larger than ours – and at least one that could harbor life.
Jupiter's Moons
When Galileo discovered Jupiter’s four largest moons in 1610, he noticed the resemblance to the solar system - a finding that would help knock down the idea of an Earth-centered universe. Indeed, these four moons are like full-fledged planets. Ganymede has its own magnetic field, Io is pockmarked with volcanoes, Europa may have an ocean under a thick layer of ice and, as the third largest moon in the solar system, Callisto is about the size of Mercury.
In total, there are more than 60 moons. The four Galilean moons, as they’re called, likely formed when Jupiter did. The others were probably captured by Jupiter’s gravity. The moons with closer orbits create thin, faint structures around Jupiter called gossamer rings.
View Moons Section -
What Does Jupiter Sound Like?
s
Jupiter Extended Mission
